Stainless Steel CR Coil/Sheet
    发布时间: 2022-04-20 19:19

Stainless Steel Coil

Tsinglong currently provides stainless steel coils made by world’s leading mills, such as YUSCO- Taiwan, POSCO- Korea, OUTOCUMPU-Europe, NTK- Japan, TISCO, BAOSTEEL-JISCOand other products. Tsinglong has enthusiastic to serve our clients with comprehensive set of products which include 2B, BA, HL, and No.4 finish that could be used in chemical tank, pipe, medical equipment, food industry, construction material, kitchen utensils and automotive hardware etc.


Stainless Steel CR Coil/Sheet






























   Product Specification and Steel Grade


ASTM

JIS

AISI

EN

Mill's Standard

Grade

S30100
S30400
S30403
S31008
S31603
S32100
S41008
S43000
S43932
S44400
S44500

SUS301
SUS304
-
SUS310S
-
SUS321
SUS410S
SUS430
-
SUS444
SUS430J1L

301
304
304L
310S
316L
321
410S
430
-
444
-

1.4310
1.4301
1.4307
1.4845
1.4404
1.4541
-
1.4016
1.4510
1.4521
-

201
202
204Cu3

Other specifications are also available up to request

Available Size

Width

Thickness

Inner Diameter

Available Steel Grade

Surface Finish

610~1524 mm

0.3~3.0 mm

610 or 508 +0/-5 mm

201, 202, 204 Cu3, 301, 304, 304L, 310S, 316L, 321, 409L, 410S, 420J2, 430, 439, 441, 444, 445

2B, 2D, BA, No.3, No.4, No.5, SB, HL

Application

Yieh Corp. stainless steel cold rolled coil is widely used in construction, surgery, kitchen essentials, etc. 304 stainless steel is suitable for the construction of external banisters and handrails, and it has good processing performance and weldability. 316 stainless steel is suitable for kitchen essentials such as equipment, cutlery and cookware, and it has good corrosion resistance and a wide range of shapes. 316L stainless steel is suitable for medical and surgical applications, which demand high levels of reliable performance.

stainless steel kitchen equipment
stainless steel kitchen equipment

Dimension and Shape Tolerance (For Reference)

Thickness (mm)630 ≤ Width < 1000 (mm)1000 ≤ Width < 1250 (mm)1250 ≤ Width < 1550 (mm)
0.25 ≤ T < 0.40±0.030±0.035-
0.40 ≤ T < 0.60±0.035±0.035-
0.60 ≤ T < 0.80±0.040±0.040-
0.80 ≤ T < 1.00±0.040±0.050±0.050
1.00 ≤ T < 1.25±0.050±0.055±0.060
1.25 ≤ T < 1.60±0.055±0.060±0.060
1.60 ≤ T < 2.00±0.065±0.070±0.080
Width Tolerance
Mill EdgeCut Edge
Aim ±10Aim -0 / +1
Surface FinishMill EdgeCut Edge
2B / BA10 mm5 mm
2D20 mm10 mm

Guarantee for Three Circles of each Inner or Outer Section

Chemical Composition & Mechanical Property :

Chemical Composition (For Reference)

JIS Specification
Spec.
JIS
G4304
G4305
G4312
Steel GradeNi% Max.Cr% Max.C% Max.Si% Max.Mn% Max.P% Max.S% Max.Mo% Max.Ti% Max.Other
SUS3016.0~8.016.0~18.00.15120.0450.03---
SUS3048.0~10.518.0~20.00.08120.0450.03---
SUS304L9.0~13.018.0~20.00.03120.0450.03---
SUS310S19.0~22.024.0~26.00.081.520.0450.03---
SUS316L12.0~15.016.0~18.00.03120.0450.032.0~3.0--
SUS3219.0~13.017.0~19.00.08120.0450.03-5xC MIN.-
SUH409L0.6010.5~11.750.03110.040.03-6xC~0.75-
SUS410S0.6011.5~13.50.08110.040.03---
SUS420J20.6012.0~14.00.26-0.40110.040.03---
SUS4300.6016.0~18.00.120.7510.040.03---
ASTM Specification
Spec.
ASTM
A240
Steel GradeNi% Max.Cr% Max.C% Max.Si% Max.Mn% Max.P% Max.S% Max.Mo% Max.Ti% Max.Other
S301006.0~8.016.0~18.00.15120.0450.03--N: 0.1 Max.
S304008.0~10.517.5~19.50.070.7520.0450.03--N: 0.1 Max.
S304038.0~12.017.5~19.50.030.7520.0450.03--N: 0.1 Max.
S3100819.0~22.024.0~26.00.081.520.0450.03---
S3160310.0~14.016.0~18.00.030.7520.0450.032.0~3.0-N: 0.1 Max.
S321009.0~12.017.0~19.00.080.7520.0450.03-5(C+N)~0.7N: 0.1 Max.
S410000.7511.5~13.50.08~0.15110.040.03---
S430000.7516.0~18.00.12110.040.03---
S439320.517.0~19.00.03110.040.03--N:0.03Max.
Al:0.15Max.
Nb+Ti = [ 0.20 + 4 ( C + N ) ] ~ 0.75


Mechanical Property (For Reference)

JIS Specification
Spec.
JIS
G4304
G4305
G4312
Steel GradeN/mm 2 MIN.
Tensile Stress		N/mm 2 MIN.
Proof Stress		% MIN
Elongation		HRB MAX.
Hardness		Bendability:
Bending Angle		Bendability:
Inside Radius
SUS3015202054095No Require-
SUS3045202054090No Require-
SUS304L4801754090No Require-
SUS310S5202054090No Require-
SUS316L4801754090No Require-
SUS3215202054090No Require-
SUH409L3601752580180°0.5 t (t<8 mm),
1.0 t (t>8 mm)
SUS410S4102052088180°1.0 time the thickness
SUS420J25402251899No Require-
SUS4304202052288180°1.0 time the thickness

ASTM Specification

Spec.
ASTM
A240
Steel GradeN/mm 2 MIN.
Tensile Stress		N/mm 2 MIN.
Proof Stress		% MIN.
Elongation		HRB MAX.
Hardness		HBW MAX.
Hardness		Bendability:
Bending Angle		Bendability:
Inside Radius
S301005152054095217No Require-
S304005152054092201No Require-
S304034851704092201No Require-
S310085152054095217No Require-
S316034851704095217No Require-
S321005152054095217No Require-
S410004502052096217180°-
S4300045020522A89183180°-
S439324152052289183180°-
