Stainless Steel HR Coil
    发布时间: 2022-04-21 12:33

OVERVIEW OF STAINLESS STEEL COIL
Stainless steel is initially produced in slabs, which are then put through a conversion process using a Z mill that converts the slab into coil prior to further rolling. As a versatile and cost-efficient material, stainless steel coil for sale with reasonable prices finds its use in many industrial applications.

Stainless Steel HR Coil


ASTM GOST JIS AISI EN Mill's Standard
Grade


S30403
S31603
S43000

S44400



12X18H10T

SUS304
-
-
SUS430

SUS444

304
304L
316L
430

444

14301
1.4307
1.4404
1.4016

1.4521

201
202
204Cu3


Other specifications are also available up to request


Available Size

Width
Thickness Inner Diameter Available Steel Grade
610~2000 mm 2.5~10.0 mm 610 +0/-5 mm 201, 202, 304, 304L, 316L

Application

Stainless steel has good processing performance and weldability. It is suitable for food processing, storage and transportation, and it can be applied to water heaters, boilers, bathtubs, auto parts (windshield wipers, muffler and molded products), medical equipment, building materials, chemical, food industry, agriculture, marine components, and so on.

stainless steel kitchen equipment




Unit Weight Limitation

Unit : ton 3 feet 1M 4 feet 5 feet
300 series 3~17 3~18 3~22 3~23 (≦5.0) / 27 (>5.0)
300 series - - 3~22 -
Remark Both Cut Edge and Mill Edge are available

Dimension and Shape Tolerance (For Reference)

Thickness Tolerance
Thickness 3 feet 1M / 4 feet 5 feet
2.00~2.49 mm ±0.05 mm ±0.06 mm -
2.50~3.14 mm ±0.06 mm ±0.07 mm ±0.09 mm
2.50~3.14 mm ±0.07 mm ±0.08 mm ±0.10 mm
2.50~3.14 mm ±0.08 mm ±0.09 mm ±0.11 mm
* Aim Tolerance = 1/2 (lower limit + upper limit)

                        Width Tolerance: Mill Edge: Aim ±10 Cut Edge : Aim -0 / +1

Camber : Max. 5 mm / 2M

Telescope & Protruding Wraps: Mill Edge: 50 mm
Cut Edge: 30 mm

Edge Crack: Mill Edge: Max. 5 mm per side
Cut Edge: Not Allowed

Chemical Composition & Mechanical Property :

Chemical Composition (For Reference)

JIS Specification
Spec.
JIS
G4304
G4305
G4312
Steel Grade Ni% Max. Cr% Max. C% Max. Si% Max. Mn% Max. P% Max. S% Max. Mo% Max. Ti% Max. Other
SUS304 8.0~10.5 18.0~20.0 0.08 1 2 0.045 0.03 - - -
SUS304L 9.0~13.0 18.0~20.0 0.03 1 2 0.045 0.03 - - -
SUS316L 12.0~15.0 16.0~18.0 0.03 1 2 0.045 0.03 2.0~3.0 - -
SUS430 0.60 16.0~18.0 0.12 0.75 1 0.04 0.03 - - -
ASTM Specification
Spec.
ASTM
A240
Steel Grade Ni% Max. Cr% Max. C% Max. Si% Max. Mn% Max. P% Max. S% Max. Mo% Max. Ti% Max. Other
S30400 8.0~10.5 17.5~19.5 0.07 0.75 2 0.045 0.03 - - N: 0.1 Max.
S30403 8.0~12.0 17.5~19.5 0.03 0.75 2 0.045 0.03 - - N: 0.1 Max.
S31603 10.0~14.0 16.0~18.0 0.03 0.75 2 0.045 0.03 2.0~3.0 - N: 0.1 Max.
S43000 0.75 16.0~18.0 0.12 1 1 0.04 0.03 - - -

Mechanical Property (For Reference)

JIS Specification
Spec.
JIS
G4304
G4305
G4312
Steel Grade N/mm 2 MIN.
Tensile Stress 		N/mm 2 MIN.
Proof Stress 		% MIN.
Elongation 		HRB MAX.
Hardness 		Bendability:
Bending Angle 		Bendability:
Inside Radius
SUS304 520 205 40 90 No Require -
SUS304L 480 175 40 90 No Require -
SUS316L 480 175 40 90 No Require -
SUS430 420 205 22 88 180° 1.0 time the thickness
ASTM Specification
Spec.
ASTM
A240
Steel Grade N/mm 2 MIN.
Tensile Stress 		N/mm 2 MIN.
Proof Stress 		% MIN.
Elongation 		HBW MAX.
Hardness 		HRB MAX.
Hardness 		Bendability:
Bending Angle 		Bendability:
Inside Radius
S30400 515 205 40 92 201 No Require -
S30403 485 170 40 92 201 No Require -
S31603 485 170 40 95 217 No Require -
S43000 450 205 22 89 183 180° -
